SERVICE/REPLACEMENT PART DIAGRAM -
CAPPING ON HEAD, KNEE, AND FOOT DECKS
Basic American Medical Products, a division of GF Health Products, Inc. www.grahamfield.com 999-0843-190A Service Manual
32
CAPS OR PLUGS ARE NOT COVERED UNDER WARRANTY.
(PACKS OF 12 CAN BE ORDERED IN THE EVENT YOU DAMAGE OR LOOSE
ANY CAPS/PLUGS ON YOUR BED - SEE BOTTOM OF PAGE 28 FOR ORDER NUMBERS)
CAPPING ON ARMS & LEGS
2X 100-4700-018
End Caps
4X 100-4715-011
Round End Caps
2X 100-4700-021
End Caps
2X 100-4700-018
End Caps
