Basic American Zenith 7000 - BED SPECIFICATIONS; 7000 MECHANICS SPECIFICATIONS; 7000 ELECTRICAL SPECIFICATIONS

Basic American Medical Products, a division of GF Health Products, Inc. www.grahamfield.com 999-0843-190A Service Manual
7
7000 ELECTRICAL
•
Power/Frequency . . . . . . . . . . . . . 120 Volt 50/60 Hz
•
Max. Amperage Draw at 120V . . . . . . . . . 4.50 Amps
•
DC Motor Output Rating . . . . . . . . . . . . . . . . 12/33V
•
Control Circuitry Output . . . . . . . . . . . . . . . . . . . . 5W
•
Water Resistance Rating . . . . . . . . . . . . . . . . . . IPX4
•
Classification . . . . . . . . . . . . . . . . . . . Class I, Type B
•
Electrical Cord . . . . . . . . . . . . #18 AWG 3 Conductor
Type SJT
•
Mode of Operations . . . . . . . . .10% Max. Duty Cycle
2 minutes on/18 minutes off
•
Internal Battery Backup Replacement . . . 9V Battery
(Note: Ilcon External Battery Pack and Charger can be
purchased separately as an accessory - see page 19.)
7000 MECHANICS
•
Overall 76” Bed Length (w/brds & wallsaver) . . . . 81.75”
•
Overall 80” Bed Length (w/brds & wallsaver) . . . . 85.75”
•
Overall Bed Width (with boards) . . . . . . . . . . . 36.00”
•
High Height* . . . . . . . . . . . . . . . . . . . . . . . . . . 30.00”
•
Low Height* . . . . . . . . . . . . . . . . . . . . . . . . . . . 8.00”
•
Max. Head/Back Deck Angle . . . . . . . . . . . . . . . . 70°
•
Max. Knee/Foot Deck Angle . . . . . . . . . . . . . . . . 30°
•
SHIPPING WEIGHT
(without rails or boards) . . . . . . . . . . . . . . . . 204 lbs.
•
MAXIMUM SAFE WORKING LOAD . . .
including Mattress, Panels, Side Rails &
Accessories taking into consideration:
patient size, proper positioning, realignment
transfer, and overall care . . . . . . . . . . . . . . . 500 lbs.
* Bed height calculated from floor surface to
top of sleep deck.
NOTE: All dimensions are in a range of +/- .25 inches
ZENITH SERIES
