Basler BE2000E - Communication Port and Software Interface

9287500995 Rev B 7
Single-phase/Three-phase select – LED #2 Blinking Slowly
LED
MODE
5
N/A
4
N/A
3
Three-phase
2
N/A
1
Single-phase
Table 6. Manual Mode (On/Off) Select
Manual Mode On/Off – LED #3 Blinking Slowly
LED
MODE
12
N/A
11
N/A
10
N/A
9
N/A
8
N/A
7
N/A
6
N/A
5
N/A
4
N/A
3
N/A
2
ON
1
OFF
Table 7. Manual Mode (If – Limit) Adjustment Ranges
Manual Mode Adjust – LED #4 Blinking Slowly
Adjustment Range: 0 to 3 Adc
Increment: 0.01 Adc
LED
Minimum Value
Maximum Value
12
2.75
3
11
2.50
2.74
10
2.25
2.49
9
2.00
2.24
8
1.75
1.99
7
1.50
1.74
6
1.25
1.49
5
1.00
1.24
4
0.75
0.99
3
0.50
0.74
2
0.25
0.49
1
0
0.24
BE2000E Human-Machine Interface
