8 9287500995 Rev B
Table 8. On-Line Operating Mode (AVR (OFF)/VAR/PF) Select
AVR (OFF) / VAR / PF Select – LED #5 Blinking Slowly
LED
MODE
12
N/A
11
N/A
10
N/A
9
N/A
8
N/A
7
N/A
6
N/A
5
N/A
4
N/A
3
Var
2
PF
1
AVR
Table 9. VAR Control Adjustment Ranges
VAR Control Adjust – LED #6 Blinking Slowly
Maximum Adjustment Range: −100% (absorb) to +100% (generate)
Increment: 1.0%
LED
Minimum Value *
Maximum Value *
12
84
100
11
67
83
10
51
66
9
34
50
8
17
33
7
1
16
6
-16
0
5
-33
-17
4
-49
-34
3
-66
-50
2
-83
-67
1
-100
-84
* Minimum and maximum values may differ from the Table 9 values if
the value has been changed in BESTCOMS™-BE2000E software.
BESTCOMS-BE2000E has 0.5 percent resolution compared to the
1.0 percent resolution of the HMI.
