www.batcafitness.com 21 Omega 4 Owner’s Manual
All Flat Washers and Nylocks are
3/8” unless otherwise noted.
Item # Part # Description Qty
44 BFP-10936
Chest Press Chrome Seat Adjustment
1
80 BFH-50210 Gas Spring 1
98 BFP-51752 SHCS 3/8” x 2 1/4” 1
100 BFP-51750 SHCS 3/8” x 2 3/4” 1
111 BFH-50146 3/8” Flat Washer 2
112 BFH-50157 3/8” Nylock 2
Step 12:
Figure 12
Make sure this bolt goes
through the bottom and top
holes of the Gas Spring
To Next Page
