Operating Instructions
Level measurement
CleverLevel
®
PL20H/S
Adaptive trigger – hygienic/industrial
Power supply Output signal
Voltage supply
8 ... 35 V DC Output type
PNP
NPN
Digital (push-pull)
4 ... 20 mA
Reverse polarity
protection
Yes Current load
100 mA max.
Current consumption
(without load)
25 mA typ.,
53 mA max.
Short circuit
protection
Yes
Power-up time
< 1.5 s Voltage drop
PNP: (+Vs –1.4 V) ± 0.5 V,
Rload = 10 kΩ
NPN: (–Vs +0.6 V) ± 0.3 V,
Rload = 10 kΩ
Features
Repeatability
± 1 mm
Hysteresis
± 1 mm
Response time
< 150 ms Leakage current
± 100 μA max.
Damping
0.1 ... 10.0 s
(adjustable)
Switching logic
Normally open (NO), active
low
Normally closed (NC),
active high
Operating conditions
Continuous Temporary (t < 1 h)
Ordering key Process connection BCID Process
temperature
at
T
amb < 50 °C
Process
pressure
Max.
process
tempera-
ture at
Tamb < 50 °C
Process
pressure
at max.
process
temperature
[°C] [bar] [°C] [bar]
G070 G 1/2 A ISO 228-1 BSC G07 –40 ... 115 –1 ... 100 135 –1 ... 100
A030 G1/2 A hygienic A03 –40 ... 115 –1 … 10 135 –1 … 5
G510 G 1/2 A DIN 3852-E G51 –40 ... 115 –1 ... 100 135 –1 ... 100
N020 1/2-14 NPT N02 –40 ... 115 –1 ... 100 135 –1 ... 100
12 / 44
www.baumer.com
–1 ... 100 135 –1 ... 100
A032
–
1 ... 5 N/A N/A
G1/2 A hygienic,
length 82 mm
A03
A031
–40 ... 115
–40 ... 150
A03
G1/2 A hygienic,
adjustable connection
