Baumer EA-34-03 - Problems and Solutions; Spare Parts

Use instruction
Code: IU.01.09.0045
Version/Revision: 2.000
Page: 34 - 55
Drying cabinet
Model: EA-34-03
the process the total safety and quality of the procedures adopted, with documented evidence of the
systematics.
To carry out these services, contact Medixx directly or through its service channels.
10. Spare parts
Description
Baumer Code
Temperature sensor bushing
H88709
Controller
H906627
Equipment motor circuit breaker 220 Vac
H890782
Equipment motor circuit breaker 380 Vac
H901500
HEPA Filter
H891053
Electrical resistance flange
H36931
Door trim
H907140
Pre filter
H891053
Electrical resistance
H55425
Fixed caster
H898003
Swivel caster with brake
H898002
Temperature sensor
H900963
Safety thermostat
H900984
Equipment fan 220 Vac
H912924
Equipment fan 380 Vac
H55564
11. Problems and Solutions
Alarms
Cause
Corrective measure
Fan is not turning on.
• Motor circuit breaker
failure.
• Contactor failure.
• Fan failure.
• Controller failure.
• Controller output fuse has
blown.
• Check the setting of the
motor circuit breaker. In
case of defect, replace
the component.
• Check the contactor
coil connection. In case
of defect, replace the
component.
• Check the engine
temperature and
whether the shaft is not
locked. In case of
defect, replace the
component.
• Check controller
programming. In case
of defect, replace the
component.
• Check fuse continuity.
In case of defect,
replace the component.
