Use instruction
Code: IU.01.09.0045
Version/Revision: 2.000
Page: 35 - 55
Drying cabinet
Model: EA-34-03
Alarms
Cause
Corrective measure
Heating is not turning on.
• Contactor failure.
• Electrical resistance failure.
• Controller failure.
• Controller output fuse has
blown.
• Check the contactor
coil connection. In case
of defect, replace the
component.
• Check whether the
thermostat is tripping
and the continuity of
the electrical
resistance. In case of
defect, replace the
component.
• Check controller
programming. In case
of defect, replace the
component.
• Check fuse continuity.
In case of defect,
replace the component.
Air leak through the door.
• Door adjustment failure.
• Door trim failure.
• Carry out door
adjustment.
• Check the condition of
the door trim. In case
of defect, replace the
component.
Increase in drying time.
• Saturated filters.
• Replace the filters.
12. Product Disposal
Baumer SA recommends that the product be returned to its manufacturing unit, free of charge, in Mogi Mirim/SP
Brazil, at Av. Prefeito Antônio Tavares Leite, 181 – CEP: 13803-330 – A/C After-Sales Management, with the
“Product Disposal” instruction. If the buyer of the product decides to dispose of it in his country and/or city, this
disposal must follow the disposal rules of the destination location and/or country, as well as send an email, letter
and/or fax to the company Baumer SA that it was discarded according to legislation.
13. Attachments
13.1. Electric scheme
Annex at the end of this manual:
E-EA-34-03.
13.2. Installation plan
Annex at the end of this manual:
P-EA-34-03.
13.3. Exploded view
Annex at the end of this manual:
V-EA-34-03.
