39
Assignment
Contact Function
1
2
3
Not assigned
Supply voltage
Supply voltage
4
5
6
1 relay contact output P1
or
1 electronic output at pin 5
7
8
9
1 relay contact output P2
or
1 electronic output at pin 8
10
11
1 relay contact output B1
or
1 electronic output at pin 11
12
13
14
15
16
17
18
19
20
Signal input, track A
Signal input, track B
Reset XP
Stop/Hold XP/Time meter
Signal input, XB counter
Reset XB
Coding input for input logic
Sensor supply –
Sensor supply +
21
22
Option RS485 / T,R-
Option RS485 / T,R+
23
24
25
26
Option RS232
TxD
–
RxD
GND
Option RS422
TxD+
TxD-
RxD+
RxD-
For protection against shock hazards as specified in EN 61010, stran-
ded conductors may only be connected using wire end ferrules with
insulating caps. Terminals which are not assigned in the factory must
not be otherwise assigned by the user. We recommend shielding
all encoder connecting leads and earthing the shield at one end.
Earthing at both ends is recommend to avoid RF interference or if
equipotential bonding conductors are installed over long distances.
Sensor connecting leads should not be laid in the same trunking as
the mains power supply cable and output contact leads.
