The adding mode is set if the chosen start count value SC is lower
than preset values P1 and P2. The subtracting mode is set if the
chosen start count value SC is greater than preset values P1 and P2.
The subtracting mode is impractical in operating modes 2 (parallel
comparison) and 3 (self-adjusting preset).
6 Technical data
Technical data - electrical ratings
Voltage supply 24/48 VAC ±10 % (50/60 Hz)
85...265 VAC (50/60 Hz)
24 VDC ±10 %, 5 % RW
Power consumption 15 VA, 8 W
Sensor supply 24/48 VAC: 12...26 VDC/80 mA
85...265 VAC: 24 VDC ±20 %/200 mA
24 VDC: 24 VDC ±20 %/200 mA
Display LED, 7-segment display
Number of digits 8-digits - totalizer
6-digits - main counter, batch counter,
tachometer, hour counter
Digit height 7.6 mm
Function Preset counter
Main counter with 2 presets
Batch counter with 1 preset
Totalizer
Hour counter
Scaling factor 0.0001...9999.99
Multitplier / batch counter 1...99
Count modes Adding or subtracting
A-B (difference counting)
A+B total (parallel counting)
Up/Down
A 90° B phase evaluation
Counting frequency 15 Hz, 25 Hz, 10 kHz programmable
Operating modes Step preset, Main preset,
Parallel alignment, Trailing preset
Data memory >10 years in EEPROM
Reset Button, electric or automatic
Outputs electronic NPN / PNP transistor switch
Outputs relay Potential-free change-over contact for
main counter Normally open/closed
potentialfree for B1
Output holding time 0.01...99.99 s
Interfaces RS232, RS422, RS485
Standard Protection class II
DIN EN 61010-1 Overvoltage category II
Pollution degree 2
Emitted interference DIN EN 61000-6-4
Interference immunity DIN EN 61000-6-2
