63
6.1 Dimensions
6.2 Default settings
The following parameters are programmed into the counter by the
factory prior to delivery:
Preset value, main counter P1 100
Preset value, main counter P2 1000
Start count value, main counter SC
0
Scaling factor, main counter XP 1.0000
Preset value, secondary counter B1
10
Batch counter multiplier 1
Display No decimal point
Pulse signal time main and
secondary counters 0.25 s
Operating mode Step preset
Counting mode for main and Track A and UP/DOWN
totalizing counter To track B
Change preset Effective after resetting
Counting frequency, main
and totalizing counters 10 kHz
Input function, secondary counter External triggering
Counting frequency,
secondary counter 10 kHz
