Programmable Operating modes
parameters Sensor logic
Scaling factor
Count mode
Control inputs
Approval UL approval / E63076
Technical data - mechanical design
Ambient temperature 0...+50 °C
Storing temperature -20...+70 °C
Relative humidity 80 % non-condensing
Connection Plug-in screw terminals
Core cross-section 1.5 mm²
Protection DIN EN 60529 IP 65 (face with seal)
Operation / keypad 10 figure keypad with 5 function keys
Housing type Built-in housing
Dimensions W x H x L 72 x 72 x 108 mm
Installation depth 108 mm
Mounting Clip frame
Cutout dimensions 68 x 68 mm (+0.7)
Materials Housing: Makrolon 6485 (PC)
Keypad: Polyester
Weight approx. 320 g (24 VDC / 85...265 VAC),
450 g (24/48 VAC)
Technical data - Trigger level
Optocoupler inputs Input circuit
Control inputs PNP- / NPN-logic
Count input
Trigger current 9...16 mA
Switch-off current <0.5 mA
Input resistance 1.65 kΩ
Reset input
Trigger current 5...8 mA
Switch-off current <0.5 mA
Input resistance 3.3 kΩ
Relay outputs Output circuit
Switching voltage max. 250 VAC / 110 VDC
Switching current max. 1 A
Switching capacity max. 150 VA / 30 W
Relay responding time 5 ms
Electronical outputs Output circuit
PNP-switching transistor Open collector
Switching voltage 24 VDC ±20 %
Switching current max. 10 mA (AC)
50 mA (DC)
NPN-switching transistor Open collector
Switching voltage max. 35 V
Switching current max. 50 mA
