Baumer NE214 - Output Response: Advanced Scenarios; Main Preset (Zero Start Count) Response; Parallel Comparison and Self-Adjusting Modes; Adding vs. Subtracting Mode Logic

NE214
48 www.baumer.com
Adding operating mode Subtracting operating mode
Main preset with pulse signal, without automatic reset (start count value at zero)
RESET
VW (P2)
VW (P1)
O
OUT 1
OUT 2
Tw
Tw
RESET
VW (P1)
VW (P2)
O
OUT 1
OUT 2
SC
T
w
Tw
Parallel comparison
RESET
VW (P2)
VW (P1)
O
OUT 1
OUT 2
The subtracting mode is not
adjustable.
Self-adjusting preset with pulse signal, without automatic reset
RESET
VW (P1)
VW (P2)
O
OUT 1
OUT 2
SC
T
w
Tw
Input of the preset value P1 corresponds to the
interval between the preliminary signal and the
final signal. This means that, if the final signal
(i.e. preset value P2) is changed, the preliminary
signal is automatically readjusted.
The adding mode is set if the chosen start count value SC is lower
than preset values P1 and P2. The subtracting mode is set if the
chosen start count value SC is greater than preset values P1 and P2.
