NE214
www.baumer.com
49
6 Technical data
Technical data - electrical ratings
Voltage supply 115/230 VAC ±10 % (50/60 Hz)
24/48 VAC ±10 % (50/60 Hz)
24 VDC ±10 %
Power consumption 7 VA, 5 W
Sensor supply 12...26 VDC / max. 100 mA
Display LED, 7-segment display
Number of digits 6-digits
Digit height 14 mm
Function Preset-/ Main counter with 2 presets
Batch counter with 1 preset, Totalizer,
Hour counter
Scaling factor 0.0001...9999.99
Multitplier / batch counter 1...999
Count modes Adding or subtracting,
A-B difference (difference counting)
A+B total (parallel counting),
Up/Down, A 90° B phase evaluation
Counting frequency 3 Hz, 25 Hz, 10 kHz programmable
Operating modes Step preset, Main preset, Parallel
alignment, Trailing preset
Data memory >10 years in EEPROM
Reset Button, electric or automatic
Outputs electronic Optocoupler
Outputs relay Potential-free change-over contact
Output holding time 0.01...99.99 s
Analoge output 0(2)...10 V, 0(4)...20 mA
Interfaces RS232, RS422, RS485
Standard DIN EN 61010-1 Protection class II, Overvoltage
category II, Pollution degree 2
Emitted interference DIN EN 61000-6-3
Interference immunity DIN EN 61000-6-2
Programmable parameters Operating modes, Sensor logic,
Scaling factor, Count mode, Control
inputs
Approval UL approval / E63076
Technical data - mechanical design
Ambient temperature 0...+50 °C
Storing temperature -20...+70 °C
Relative humidity 80 % non-condensing
E-connection Plug-in screw terminals
Core cross-section 1.5 mm²
Protection DIN EN 60529 IP 65 (face with seal)
Operation / keypad Membrane with softkeys
Housing type Built-in housing
