NE214
50 www.baumer.com
Dimensions W x H x L 96 x 48 x 124 mm
Installation depth 124 mm
Mounting Clip frame
Cutout dimensions 92 x 44 mm (-0.6)
Materials Housing: Makrolon 6485 (PC)
Keypad: Polyester
Weight approx. 350 g (AC), 250 g (DC)
Technical data - Trigger level
Comparator inputs Input circuit
Inputs PNP- / NPN-logic
Input level Programmable
Input level Low 0...2 VDC
Input level High 3...40 VDC
Input resistance 3 kΩ
Relay outputs Output circuit
Switching voltage max. 250 VAC / 110 VDC
Switching current max. 1 A
Switching capacity max. 150 VA / 30 W
Relay responding time 5 ms
Electronical outputs Output circuit
Optocoupler short-circuit proof
Switching voltage max. 40 V
Switching current max. 15 mA
Residual voltage <1 V
Technical data - Analog output
Resolution 12 bit (4096 steps)
Output ranges
- with current output 0...20 mA
4...20 mA (programmable)
1 bit value: 4.884 μA
Max. load (burden): 500 Ohms
- with voltage output 0...10 V
2...10 V (programmable)
1 bit value: 2442 mV
Min. load (burden): 1000 Ohms
Accuracy ±0.1% of final value
Non-linearity ±1 LSB
Output temp. coefficient Typically ±50 ppm/°C
Offset tolerance Max. ±0.50 μA, Max. ±0.25 mV
Offset temp. coefficient Max. ±20 ppm/°C
Reference voltage -2.5 V
Insulation 250 VRMS min. output to tacho logic
Other All outputs are short-circuit proof
All other functions electrically isolated
