Connections on the front side
Instruction handbook b maXX 5000
Document No.: 5.09021.16 Baumüller Nürnberg GmbH
190
of 328
7.15
X6 Analog inputs/
outputs
There are two analog inputs and outputs available.
Pin assignment X6
Pin No. Assignment
1 Analog input 1 +
2 Analog input 2 +
3 Ground
4 Analog output 1 +
5 Analog output 2 +
6 Analog input 1 -
7 Analog input 2 -
8 Analog output 1 -
9 Analog output 2 -
Inputs
Resolution 12 bit
Type Differential input
Input resistance Approx. 50 k
Input current max. 200 µA
Sampling rate 125 µs
Input voltage +10 V to -10 V
Outputs
Resolution 12 bit
Output voltage +10 V to -10 V
Output curr
ent max. 1 mA
Update rate 62.5 µs
Short circuit proof Limited, max. 10 s
