Baumuller DSD2 Series User Manual

TAM 00699 25
DSD2 045 – 132 04/2018
Three-phase synchronous motor English
8.6 Control terminal: Resolver
Pin
Signal
Option for allocation
KTY on encoder
socket
View of the contact side of the built-in box
1
2
3
4
5
6
7
8
9
10
11
12
cos –
-
-
-
sin –
sin +
-
cos +
-
ref +
-
ref –
cos –
-
-
-
sin –
sin +
K – or R2
cos +
K + or R1
ref +
-
ref –
Figure 7: pole assignment resolver
8.7 Control terminal: SRS / SRM 50
(absolute value encoder with Hiperface terminal of SICK / Stegmann)
Pin
Signal
Option for allocation
KTY on encoder
socket
View of the contact side of the built-in box
1
2
3
4
5
6
7
8
9
10
11
12
Cos -
+ 485
-
-
sin +
sin -
– 485
cos +
-
GND
-
+ U
cos -
+ 485
K + or R1
K – or R2
Sin +
sin -
– 485
cos +
-
GND
-
+ U
Figure 8: pole assignment SRS / SRM 50
