Baumuller DSD2 Series User Manual

TAM 00699 26
DSD2 045 – 132 04/2018
Three-phase synchronous motor English
8.8 Control terminal: SEK / SEL 52
(encoder with Hiperface-terminal of SICK / Stegmann)
Pin
Signal
Option for allocation
KTY on encoder
socket
View of the contact side of the built-in box
1
2
3
4
5
6
7
8
9
10
11
12
cos -
+ 485
-
-
sin +
sin -
– 485
cos +
-
GND
-
+ U
cos -
+ 485
K + or R1
K – or R2
sin +
sin -
– 485
cos +
-
GND
-
+ U
Figure 9: pole assignment SEK/ SEL 52
8.9 Control terminal: ECN 1313 / EQN 1325
(encoder with EnDat 2.1-port of Heidenhain)
Pin
Signal
Option for allocation
KTY on encoder
socket
View of the contact side of the built-in box
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
U
p
-
-
0 V
-
-
U
p
Clock
Clock inv.
0 V
-
B +
B –
Data
A +
A –
Data inv.
U
p
-
-
0 V
K + or R1
K – or R2
U
p
Clock
Clock inv.
0 V
-
B +
B –
Data
A +
A –
Data inv.
Figure 10: pole assignment ECN 1313 / EQN 1325
8
10
9
2
5
7
6
1
11
13
16
17
12
14
15
3
4
