Baumuller DSD2 Series User Manual

TAM 00699 30
DSD2 045 – 132 04/2018
Three-phase synchronous motor English
9.5 Specifications for required coolant volume flows
Motortype
Volume
flow
in l / min
Pressure
decrease
 15 % in bar
Heating
in K
Max. coolant
pressure in
bar
Connection(2x)
in mm
DSD2-056SO..W
5
0,94
3
6
Internal thread
G1/4“
DSD2-056MO..W
5
0,96
4
6
Internal thread
G1/4“
DSD2-056LO..W
5
0,98
5
6
Internal thread
G1/4“
DSD2-071SO..W
5
0,5
6
6
stainless steel
tube Ø8 x 1
DSD2-071MO..W
5
0,65
7
6
stainless steel
tube Ø8 x 1
DSD2-071LO..W
5
0,8
8
6
stainless steel
tube Ø8 x 1
DSD2-100SO..W
5
0,55
8
6
stainless steel
tube Ø8 x 1
DSD2-100MO..W
5
0,65
9
6
stainless steel
tube Ø8 x 1
DSD2-100LO..W
5
0,85
10
6
stainless steel
tube Ø8 x 1
DSD2-100BO..W
5
1,0
12
6
stainless steel
tube Ø8 x 1
DSD2-132KO..W
15
0,35
3
6
Internal thread
G1/2“
DSD2-132MO..W
15
0,35
4
6
Internal thread
G1/2“
DSD2-132LO..W
15
0,35
4
6
Internal thread
G1/2“
DSD2-132BO..W
15
0,35
5
6
Internal thread
G1/2“
DSD2-132XO..W
15
0,35
5
6
Internal thread
G1/2“
DSD2-132YO..W
15
0,35
6
6
Internal thread
G1/2“
DSD2-132YZ..W
15
0,35
6
6
Internal thread
G1/2“
Table 7: coolant volume flows
