Baxi Fourtech 1.24 - Wiring Diagram; Electrical Cable Colour Codes

63
926.116.5 - en
INSTRUCTIONS FOR FITTERS
33. WIRING DIAGRAM
24 F
Cable colours
C = Light blue
M = Brown
N = Black
R = Red
G/V = Yellow/Green
B = White
V = Green
DETECTION/IGNITION
ELECTRODE
THERMOSTAT
THREE-WAY VALVE
PUMP
FAN
DOMESTIC WATER
PRIORITY SENSOR
DHW NTC SENSOR
EXTERNAL
PROBE
HYDRAULIC
PRESSURE SWITCH
SAFETY
THERMOSTAT
AIR PRESSURE SWITCH
CH NTC SENSOR.
AMB. THERM./REMOTE CONTR
CG_2075 / 1001_1806
