Wired control TXW1AC-User and installation manual
Read and keep this manual.
DESCRIPTION
FIGURE
SPECIFICATIONS
Wired control
TXW1AC
Dimensions(hight/wide/dedepth):
120mmx120mmx20mm
Weight: 168 g
2 screws
M4x20
User and Installation
manual
Long connection
wiring
Length: 5000mm
Weight: 99 g
Short connection
wiring
Length: 50mm
Weight: 10 g
PACKAGING CONTENT
BUTTONS DESCRIPTION
EN
