Bay-Tek CONNECT 4 HOOPS User Manual

38
AAMB10E-HD
Motherboard
Note: Later games may have
different colored sockets.
The connections are the same.
AC POWER IN WIRING DIAGRAM
AC Power to
Power Supply
A5CORD5001
AAC-
A5PS1013
Power Sup-
Power In Cord
From Wall
A5CORD5-A
Outlet Strip
A5OU1000
AC Power In cable
AACE15021
AACE15022
AACE15023
White
Connectors
Orange
Connectors
A5CORD1
AACE15022
Front Console
AACE15043
White
Connectors
Middle Section
A5CORD5003
Outlet Strip
A5OU5000
On/Off
Rocker
Switch
Monitor
A5MO0065A
Power Cord is
attached to
monitor
Line Filter
A5FI9010
Power In Cord
From Wall
A5CORD5-A
A5CORD50
Rear Section
Middle Section
Orange
Connectors
AC Power In cable
AACE15042
AC Bleeder
Board
AACB15001
Note:
This section is only for
early games manufactured
before 9/5/2019
AC power to
power supply
A5CORD5-A
AC power to
monitor
A5CORD50
