Bay-Tek CONNECT 4 HOOPS User Manual

37
AAMB10E-HD
Motherboard
AACB5156
Power Dist.
Board
AACE15038
AACE15037
12 VDC In
AACE15017
AACB9604
I/O Aux Board
AACB9604
I/O Aux Board
Right Side
Board Address
Dip #1 ON
Dip #2 OFF
Left Side
Board Address
Dip #1 OFF
Dip #2 OFF
12 V POWER SUPPLY & SOUND WIRING DIAGRAM
AACB10000
Control Board
# 8 # 7 # 6 # 5 # 4 # 3 # 2 # 1
Rear Section
Front Console
Middle Section
Middle Section
AACE15015
AACE15016
Pink
Connectors
Gold
Connectors
+
Speaker
AACE8811
3.3 Ohms
AACE15008
+
Speaker
AACE8811
3.3 Ohms
AACB9600A
Audio Amplifier
Plug “input”
cable into
end of
A5CEAU010
A5CE2300
Audio Filter
A5CEAU010
Audio Jack from
Green Socket on
Motherboard to
Audio Filter cable
Note: Later games may have
different colored sockets.
The connections are the same.
