41
Problem Probable Cause Remedy
LED white rear
cabinet lighting
above hoops not
working
LED’s receive 12 Volts DC
from power supply through
The Power Distribution
Board.
Faulty LED light.
Check for proper connection from power supply to Power
Distribution Board.
Refer to wiring diagram. Check connections and reseat
cables from Power Distribution Board to LED lights.
Cables # AACE15006, AACE15005, AALB15044, and
AALB15045.
Light strips are wired in series. Swap the 2 light strips to
identify a faulty LED strip. Replace as needed. Part #
AALB15044 or AALB15045
One of the left
side, red colored
LED strips
not working
LED’s receive 12
Volts DC from
Control Board in
the rear of the
game.
Refer to “How to
Access Rear
Control Board”
If all colored cabinet lights
are not functioning, check
power into the Control
Board from the Power
Distribution Board.
If single LED strip is out,
check cable. LED’s are
wired in series. Refer to
wiring diagram.
Faulty LED
Refer to wiring diagram. Check connections and reseat
cables from Power Distribution Board in the front of the
cabinet to Control Board in the back.
Cables # AACE15017, AACE15016, and AACE15015
Check for 12 volts coming from Power Distribution Board
in the rear of the cabinet on red and black wires.
If no 12 volts DC, ensure 12 volts is coming into board on
cable # AACE15018. If voltage is present - replace
Control Board part # AACB10000
Refer to wiring diagram. Cables # AACE15018,
AACE15019, AACE15020, AALB15042, AACE15007,
AACE15040, AACE15039, and AACE15041
Swap LED connector from one socket to the other to
verify. Replace LED as needed.
TROUBLESHOOTING GUIDE
LED white front
panel light not
working
LED’s receive 12 Volts DC
from power supply through
The Power Distribution
Board.
Faulty LED light.
Check for proper connection from power supply to Power
Distribution Board.
Refer to wiring diagram. Check connections and reseat
cable from Power Distribution Board to LED lights.
Cables # AACE15003, and AALB15043
Replace Panel Stick Light. Part # AALB15043
Upper marquee
LED’s not
working
LED’s receive 12 Volts DC
from power supply through
The Power Distribution
Board.
Faulty LED light.
Check for proper connection from power supply to Power
Distribution Board.
Refer to wiring diagram. Check connections and reseat
cables from Power Distribution Board to LED lights.
Cables # AACE15006, AACE15005, and AACE10045
Light strips are wired in series. Swap the 2 light strips to
identify a faulty LED strip. Replace as needed. Part #
AALB15047 or AALB15048
To Next Page
