Bay-Tek Piano Keys User Manual

37
PART # DESCRIPTION
PART # DESCRIPTION
PARTS LIST
9654K191 Spring
A5BK1013 Bracket, Pushbutton/Counters
A5BK9999 Bracket, Power Supply Mounting
A5CA7000 Carpet, Black
A5CB1499 Coin Box, White
A5CO4203 Cover, Speaker
A5DE0042 Decal, Menu/Vol
A5DE13000 Decal, Monitor Cover
A5DE13001 Decal, Front Cabinet Outside
A5DE13002 Decal, Front Door Inside
A5DE13003 Decal, Instructions
A5DE13004 Decal, Marquee Arch
A5DE13005 Decal, Marquee Logo
A5DE13006 Decal, Marquee Light Strip
A5DE13007 Decal, Piano Inset
A5DE13008 Decal, Side Left
A5DE13009 Decal, Side Right
A5DE13010 Decal, Monitor Surround Strip
A5DE13011 Decal, Marquee Flourish
A5FI9010 Filter, F1700ca06, Inline
A5HO1003 Holder, For Light Bars
A5LI1302 LIGHT,"EGG",26mm 3pcs SM 5050
A5LK2001 Lock, Cash Box, A05/E00 Key Code
A5LK5002 Lock, 7/8", H95 Key Code
A5ME2035 Ticket Tray, Metal
A5ME4182 Metal, Cashbox Guide
A5ME5300 Metal, Keyboard Front
A5ME5301 Metal, Keyboard Flag
A5PL4200 Plate, Up Stacker
A5PL8900 Plate, Blanking, Bill Validator
A5PS1013 Power Supply, EVGA 500
A5RO5300 Rod,3/4"Od,.62"Id.065" Wall
A5RVNY010 Rivet, Nylon, .148" Hole Dia
A5TD1 Ticket Dispenser, Entropy
A5VF5300 Vacuum Form, Keys, Piano Keys
A5VF8000 Vac Form, Monitor Cover
A5CBL5900 Cable, USB, Male A To Male Micro
A5CE2300 Audio Filter Cable
A5CEAU010 Audio Cable
A5CORD35A Cord,15',Hdmi W/Ferrite Cores
A5CORD5 Cord, AC Computer Cord, 6.5'
A5OU1000 Outlet,Strip,Six,15amp,125v
AACBL4A-DOOR Coin Mech Door Cable
AACE13000 Cable Assy, Piano Key #1 Light Power
AACE13001 Cable Assy, Piano Key #2 Light Power
AACE13002 Cable Assy, Piano Key #3 Light Power
AACE13003 Cable Assy, Piano Key #4 Light Power
AACE13004 Cable Assy, Piano Side Light Power
AACE13005 Cable Assy, Power Dist to Door Board
AACE13006 Cable Assy, Marquee Light Split Power
AACE13007 Cable Assy, Monitor Light Power
AACE13008 Cable Assy, Game Play Light Power
AACE13010 Cable Assy, Speaker Wires
AACE13011 Cable Assy, Menu/Select
AACE13012 Cable Assy, #1 & #8 Marquee Light
AACE13013 Cable Assy, #3 & #6 Marquee Light
AACE13014 Cable Assy, Ticket Tray/Coin Door/Dba
AACE13015 Cable Assy, Monitor Light
AACE13016 Cable Assy, Outside Piano Light
AACE13017 Cable Assy, Key Control Board Power
AACE13018 Cable Assy, Game Directions Light
AACE13019 Cable Assy, Top Marquee Glow Light
AACE13020 Cable Assy, Piano Keys Marq Outline
AACE13021 Cable Assy, Piano Key Sensors
AACE13022 Cable Assy, Audio Board Power
AACE13023 Cable Assy, Line Filter
AACE13024 Cable Assy, PS To Main Bd Ground
AACE13025 Cable Assy, Ticket Disp To Hinge Ground
AACE13026 Cable Assy, Marquee Light Splitter
AACE13027 Cable Assy, Door Hinge To Ground Stud
AACE13028 Cable Assy,#4 & #5 Marq Light Power
AACE13029 Cable Assy,#2 & #7 Marq Light Power
AACE13030 Cable Assy, Marquee Addressable Power
AACE13032 Cable Assy, Piano Lights
AACE13033 Cable Assy, Piano Lights
AACE13034 Cable Assy, Marquee Stick Light
AACE13035 Cable Assy, Servicing Square Light
AACE13036 Cable Assy, Marquee Splitter Light Pwr
AACE13037 Cable Assy, Inside Piano Side Light
AACE13038 Cable Assy, Power To Cabinet Light
AACE13039 Cable Assy, Egg Light Power From Brd
AACE13040 Cable Assy, Egg Light Power
AACE1710 Cable, Door Ground
AACE1715 Cable Assy, Ground Strap
AACE8811 Speaker, 4 Ohm, 25watt, Boss
AACO1020 Counter Assy, No Feet
AAPB2700 Push Button Assembly
AASW200 Low Ticket Switch
W5HG1025 Hinge,16",Double Bend
W5HG1065 Hinge,5-75,Single Bend
W5KE5000 Keeper, Lock
W5TM4000 T-Mold,7/8""Black
W5TM4001 T-Molding,7/8"White
A5CB9600 PCB, Audio Amplifier
AAMO5503-PTL Monitor, 55" TV
AACB13000 PCB, Key Controller
AACB3400A Assy, Sensor
AACB5156 PCB, Power Dist.
AACB9604 Board, Door Interface
AAMB10-HD Mother Board,Qc5000-Itx/Ph W/Hard Drive
