TX1500 Manual Combined 1Oct03 PSC Page 17 of 31 Matrix
ALARM MENUS
Alarm handling of the Tx1500 is programmed in from the Alarm Menu screens.
Up to four actions can be carried out following each alarm activation. Eg four cameras could move to preset
positions to triangulate onto an event.
On selection of Alarm Menus the following screen is displayed
This example shows a system with a single 16 input alarm card.
The Tx1500 will display the total number of alarms that can be
programmed based on the Maximum Alarm number set in the
System Basics menu.
Enter the alarm number you wish to program using the 0-9 keys and 2 digits. Eg enter 01 for alarm 1. The
following screen will then be displayed.
Each of the four actions can allow a camera to be moved to a
preset position and for this camera to be displayed on a monitor
output. In addition, if the monitor was sequencing before the alarm
occurred, after ‘time’ seconds the sequence is re-started.
If alarms are taken into the local alarm input of a telemetry
receiver that supports local alarms, ie
Rx100/Rx400DC/Rx457/Rx557, pre must be set to 00 as the
preset will depend on the receiver alarm input. (See the receiver
manual for more details on local alarms.)
This simple example shows alarm 1 moving camera 1 to preset 1
and display on monitor 1.
next and prev allow setting the alarm actions for the next and
previous alarm inputs.
Input Action :
Sets the action for the ALARM 00 input on the Tx1500 monitor board. Use +/- to cycle through the options.
No Action – ALARM 00 is not used.
Disable Alm – is used to disable all alarms when ALARM 00 is shorted to GND.
Alarm 00 – ALARM 00 is used in addition to the Tx1500/AL16 alarm card inputs.
Alarm Beep Time :
Number of seconds that the keyboards ‘beep’ following an alarm input. Use +/- to cycle through the values.
0, 4, 6, 8, 10, 15, 20 Seconds
Alarm Stack :
The Tx1500 alarm handling can be automatic, ie the system will drive cameras to presets as alarms occur or
require an operator input before the alarm is actioned. Use the +/- to toggle between Automatic and Manual.
Automatic – Alarm activations are handled automatically
Manual – The ALARM key must be pressed to acknowledge an alarm activation
Relay 1 Time :
The number of seconds that the change over relay on the Tx1500 monitor board is active following an alarm.
Use +/- to cycle through the various time delays.
10, 30, 60, 90, 120, 150, 200 or 250 seconds.
You have 16 alarms
enabled and connected
Edit Alarm number 00
Input Action Disable Alm
Alarm Beep Time 6 Seconds
Alarm Stack Automatic
Relay 1 Time 60 Seconds
Return
Alarm 1
kbd cam mon pre time
Action 1 01 1 01 30s
No Action 1 01 1 00 30s
No Action 1 01 1 00 30s
No Action 1 01 1 00 30s
Return Exit next prev
