SEQUENCES
Each of the 8 monitor outputs of the Tx1500 can sequence between all or specific cameras. Each camera can
be individually added or removed from each monitor sequence to create a system where say in a retail
environment public store monitors are prevented from displaying sensitive areas of the store whilst monitors in
the security office can sequence all cameras.
Individual cameras can be added or removed from sequences in banks of 8 as shown on the following screen:
If a camera greater than the Maximum Camera Number is added
to a sequence this camera will be ignored when the sequence is
running.
Selecting Cameras 01 – 08 will display the following screen
Monitors 1 to 8 are shown with monitor 1 the top line and monitor 8
the bottom line.
The first item is the type of sequence or the dwell time if running a standard sequence. The screen on the left
shows all the variants of sequences and dwell times.
Sequence types :
2/5/15… Second – standard sequence starting at the lowest camera. Waiting for the dwell time before
displaying the next camera.
Random – The cameras are sequenced as above from lowest to highest but the dwell time is
random.
Full Rand – In Full Random the monitor will display a completely random camera for a random
dwell. This is useful for public display monitors on shop floor to prevent shoplifters
remembering the displayed sequence.
A camera will be in a specific monitor’s sequence if a Y is displayed or be skipped if an N is displayed.
Use the + or – keys to toggle between Y and N.
Next8 will allow display of the next bank of 8 cameras.
Sequence Setup Selection
Cameras 01 - 08
Cameras 09 - 16
Cameras 17 - 24
Cameras 25 - 32
Cameras 33 - 40
Cameras 41 - 48
Cameras 49 - 56
Cameras 57 - 96
Return
monitor sequence setup
cam 1 2 3 4 5 6 7 8
1 2 Second Y Y Y Y Y Y Y Y
2 5 Second Y Y Y Y Y Y Y Y
3 15 Second Y Y Y Y Y Y Y Y
4 20 Second Y Y Y Y Y Y Y Y
5 25 Second Y Y Y Y Y Y Y Y
6 30 Second Y Y Y Y Y Y Y Y
7 Full Rand Y Y Y Y Y Y Y Y
8 Random Y Y Y Y Y Y Y Y
Return menu Next8
