TX1500 Manual Combined 1Oct03 PSC Page 20 of 31 Matrix
CAMERA TYPES
These screens are used to set the type of telemetry for each camera and which monitor(s) and keyboard(s) are
allowed to view and control each camera.
The cameras are again displayed in banks of 8 as shown on the following screen:
Start at Cameras 01 – 08 to display the setup screen
This example shows Camera 1,2,4 & 6 with coax telemetry and
able to be viewed on all monitors and controlled from all
keyboards.
Camera 3 is a static camera that can be viewed on all monitors
apart from monitor 2.
Camera 5 is driving via RS485 and can only be viewed on monitor
2 and controlled by keyboard 1.
Cameras 7 & 8 are not fitted.
The choices for camera type are:
BBV coax – Standard BBV up-the-coax telemetry (Rx100/200/300/400P/400DC)
BBV 485 TP – BBV RS485 telemetry also used when driving a starcard/converter
Static – Telemetry is disabled
Not Fitted – This will be used in future version of the firmware.
BBV coax would be used to control the existing range of BBV up-the-coax receivers.
Rx100 for dome control. Rx200/300/400P for AC heads, Rx400DC for high/variable speed 24Vdc heads.
Remember 250M of RG59 grade cable or 500M of CT125 grade cable.
BBV 485 TP is used to drive the new advanced range of addressable BBV receivers that are controlled using
two wire RS485. The RX457 is used when driving AC pan/tilt heads and the RX557 is used for high/variable
speed 24Vdc heads. Both receivers offer additional features including an On Screen Display with an advanced
menu system, 8 local alarm inputs, wide input supply, DIP switch addressable allowing either star or daisy
chained wiring.
3
rd
party domes and selected telemetry receivers can be controlled via RS485 and a BBV
STARCARD/CONVERTER. Full details can be found on the BBV web site www.bbvcctv.com
Kbd: If a keyboard is allowed to control the camera select Y or if the keyboard can only view but not control the
camera select N.
Monitor: Select Y if the camera can be displayed on each monitor or N if not. This allows cameras to be hidden
from specific monitors/operators.
Camera Setup Selection
Cameras 01 - 08
Cameras 09 - 16
Cameras 17 - 24
Cameras 25 - 32
Cameras 33 - 40
Cameras 41 - 48
Cameras 49 - 56
Cameras 57 - 96
Return
Camera 01-08 Kbd Monitor
1234 12345678
01 BBV coax YYYY YYYYYYYY
02 BBV coax YYYY YYYYYYYY
03 Static YYYY YNYYYYYY
04 BBV coax YYYY YYYYYYYY
05 BBV 485 TP YNNN NYNNNNNN
06 BBV coax YYYY YYYYYYYY
07 Not Fitted YYYY YYYYYYYY
08 Not Fitted YYYY YYYYYYYY
Return Menu Next8
