(A) RELAY TYPE
Input (IN)
Number of Pins：8.
Input Common Pin：COM1
Output (OUT):
Number of Pins：8.
Type：for RELAY.
Max. Load：250VAC, 30VDC, 3A
Output Common Pin：COM2
RELAY durance：About 100,000 Times.
LED light will ON when work.
(B) SSR TYPE
Input (IN)
Number of Pins：8.
Input Common Pin：COM1
Output (OUT):
Number of Pins：8.
Type：for RELAY.
Max. Load：24~280VAC, 3A (Only for AC)
Output Common Pin：COM2
RELAY durance：About 100,000 Times.
LED light will ON when work.
CONTROL I/O Pins
OP-08
I/O
BDE-2007
Control I/O
1 PIN 25
2 PIN 24
3 PIN 23
4 PIN 22
5 PIN 21
6 PIN 20
7 PIN 19
Input
8 PIN 18
1 PIN 13
2 PIN 12
3 PIN 11
4 PIN 10
5 PIN 9
6 PIN 8
7 PIN 7
Output
8 PIN 6
