BDE BDE-2007 - 6-5 Modbus

22
§ 6-5 MODBUS
Bit I/O
R/W Type Function Address
Modbus
address
SCALE
Output
RBit
R:02
0000 10001
ZERO
RBit
R:02
0001 10002
M.D.
RBit
R:02
0002 10003
G.W.
RBit
R:02
0003 10004
N.W.
RBit
R:02
0004 10005
Tared
RBit
R:02
0005 10006
OVER
RBit
R:02
0030 10049
Zero
Range
RBit
R:02
0031 10050
SP1
RBit
R:02
0032 10051
SP2
RBit
R:02
0033 10052
FF
RBit
R:02
0034 10053
HI
RBit
R:02
0035 10054
LO
RBit
R:02
0036 10055
Finish
RBit
R:02
0037 10056
Unstable
/ Error
Data Register
R/W Type Function Address
Modbus
address
Description
R Word
R:04
0000 ~ 0001
30001 ~ 30002
Same as
display
R Word
R:04
0002 ~ 0003 30003 ~ 30004
G.W.
R Word
R:04
0004 ~ 0005 30005 ~ 30006
N.W.
R Word
R:04
0006 ~ 0007 30007 ~ 30008
Tare Value
R Word
R:04
0008 ~ 0009 30009 ~ 30010
Accumulation
R Word
R:04
0010 ~ 0011 30011 ~ 30012
Total Count
R Word
R:04
0012 ~ 0013 30013 ~ 30014
Actual Final
R/W Word
R:03,W:06
0000 ~ 0001 40001 ~ 40002 Final
R/W Word
R:03,W:06
0002 ~ 0003 40003 ~ 40004 SP1
R/W Word
R:03,W:06
0004 ~ 0005 40005 ~ 40006 SP2
R/W Word
R:03,W:06
0006 ~ 0007 40007 ~ 40008 FF
R/W Word
R:03,W:06
0008 ~ 0009 40009 ~ 40010 HI
R/W Word
R:03,W:06
0010 ~ 0011 40011 ~ 40012 LO
Bit I/O
R/W
Type Function
Address
Modbus
Address
SCALE
Intput
R/W
Bit
R:01,W:05
0000 00001
ZERO
R/W
Bit
R:01,W:05
0001 00002
TARE
R/W
Bit
R:01,W:05
0002 00003
TARE Cleared
R/W
Bit
R:01,W:05
0003 00004
Display G.W.
R/W
Bit
R:01,W:05
0004 00005
Display N.W.
R/W
Bit
R:01,W:05
0030 00049
Add 1
R/W
Bit
R:01,W:05
0031 00050
Clear ACC and
Count
R/W
Bit
R:01,W:05
0032 00051
Start Batch
R/W
Bit
R:01,W:05
0033 00052
Stop Batch
