2/8
From behind, before installation
From the front, after installation
• Paste the template
• Drill as instructed
• Insert screws, but do not screw them
fully home
• Pass the cable where it is supposed
to go through.
• Cut one of the footprint for the wire.
Position the sensor and tighten the two screws. Leave wires long
enough to reach the terminal block.
12-24V
AC/DC
COM
NO
NC
This device may be fixed on the ceiling, as long as the
spherical part of the sensor is facing in the direction
opposite the door, and as long as an angular position of
around 70° is chosen for the antenna.
For the mounting on the
upper part of the door
operator profile, use the EBA
support.
For a mounting into the ceiling, use the ECA embedding
support.
For a better water tightness,
use the ERA protection cap.
