84
4233 5000 13
•
SO
2
concentration
ppm
1
•
NO
x
concentration
ppm
2
•
Pressure dew point
°C
-31
•
Pressure dew point
°F
-23.8
•
Oil vapour
mg/m³ 0.1
•
Taste and odour
free
Data at 13 bar inlet pressure
Unit dMED
025
dMED
035
dMED
045
dMED
075
dMED
090
Volume flow at dryer inlet
l/min
1246
1727
2237
3710
4474
Volume flow at dryer inlet cfm 44.5 61.4 78.4 131.4 159
Pressure drop over dryer mbar
646 926 722 757 644
Pressure drop over dryer psi
9,37 13,4 10,47 10.98 9.34
Time of half a cycle s
154 154 154 154 154
Regeneration time s
120 120 120 120 120
Pressurization time s
34
34
34
34
34
Installed power V
340 340 340 340 340
Net mass kg
220
240 280 320 360
Net mass lb
485
529 617 703 794
Air quality (Pharmacopeia)
•
O
2
concentration
%
20<X<
22
•
CO
2
concentration
ppm 500
•
CO concentration
ppm
5
•
SO
2
concentration
ppm
1
•
NO
x
concentration
ppm
2
•
Pressure dew point
°C
-31
•
Pressure dew point
°F
-23.8
•
Oil vapour
mg/m³
0.1
•
Taste and odour
free
Unit dMED
110
dMED
150
dMED
220
dMED
300
Volume flow at dryer inlet l/min 5465 7447 10902 14866
Volume flow at dryer inlet cfm 192.8 262.7 385.6 525.5
Pressure drop over dryer mbar
646 926 722 757
Pressure drop over dryer psi
9,37 13,4 10,47 10.98
Time of half a cycle s
154 154 154 154
Regeneration time s
120 120 120 120
Pressurization time
s
34
34
34
34
Installed power W
340
340
340
340
