Becker BDC-i440R User Manual

Function Profile Description
22.XX
Light barrier 1
If the light barrier signals when travelling in the CLOSE direction (display: =Lb), the door is brought to
an immediate halt and reversed for 3 seconds (can be set using P.451).
If the beam of light is interrupted and then released again while the door is open or being opened, the
stay-open time begins a new count (only if reclosing is activated).
In order to achieve Category 2 according to EN 13849-1, testing is necessary using a switching out-
put and the "External testing" function.
22.00 NC – normally closed | Restart stay-open time 1 | Without testing
22.01 NO – normally open | Restart stay-open time 1 | Without testing
22.02 NC – normally closed | Restart stay-open time 1 | External testing
22.03 NO – normally open | Restart stay-open time 1 | External testing
22.04 NC – normally closed | Restart stay-open time 2 | Without testing
22.05 NO – normally open | Restart stay-open time 2 | Without testing
22.06 NC – normally closed | Restart stay-open time 2 | External testing
22.07 NO – normally open | Restart stay-open time 2 | External testing
22.08 NC – normally closed | Stay-open time 3 seconds | Without testing
22.09 NO – normally open | Stay-open time 3 seconds | Without testing
22.10 NC – normally closed | Stay-open time 3 seconds | External testing
22.11 NO – normally open | Stay-open time 3 seconds | External testing
22.12 NC – normally closed | Last active stay-open time | Without testing
22.13 NO – normally open | Last active stay-open time | Without testing
22.14 NC – normally closed | Last active stay-open time | External testing
22.15 NO – normally open | Last active stay-open time | External testing
23.XX
Light barrier 2
If the light barrier signals when travelling in the CLOSE direction (display: Lb=), the door is brought to
an immediate halt and reversed for 3 seconds (can be set using P.451).
If the beam of light is interrupted and then released again while the door is open or being opened, the
stay-open time begins a new count (only if reclosing is activated).
In order to achieve Category 2 according to EN 13849-1, testing is necessary using a switching out-
put and the "External testing" function.
23.00
…
23.15
See 22.XX Light barrier 1
24.XX
Pull-in safety device
OPEN
If the pull-in safety device signals during travel, the error code E.341 appears and the door is
stopped. In the case of the OPEN pull-in safety device, travel in the OPEN direction is blocked. Travel
in the opposite direction is possible in dead-man mode. A triggered pull-in safety device is acknow-
ledged in the CLOSE limit position. In order to achieve Category 2 according to EN 13849-1, testing
is necessary using a switching output and the "External testing" function.
24.00 NC – normally closed | External testing
24.01 NC – normally closed | Without testing
25.XX
Pull-in safety device
OPEN and CLOSE
If the pull-in safety device signals during travel, the error code E.342 appears and the door is
stopped. Travel in dead-man mode is possible. A triggered pull-in safety device is acknowledged in
the CLOSE limit position. In order to achieve Category 2 according to EN 13849-1, testing is neces-
sary using a switching output and the "External testing" function.
25.00 NC – normally closed | External testing
25.01 NC – normally closed | Without testing
24
