P. [Unit] Setting
range
Description Ex works
210
0..5
If using an absolute value encoder:
Reprogramming the limit positions
With this parameter, the programming of the limit positions is restarted. After activ-
ating the process, travel to the relevant limit positions is carried out in dead-man
mode, and they are saved by pressing and holding the rotary-push button. The fol-
lowing setting options can be selected:
0: Abort: no limit positions are reprogrammed.
1: Direction of rotation, CLOSE limit switch, OPEN limit switch, pre-limit switch and,
where applicable, floor position and, where applicable, partial opening position are
programmed.
2: The OPEN and, where applicable, partial opening position are programmed.
3: The CLOSE and OPEN limit switches are programmed.
4: The partial opening position is programmed.
5: Direction of rotation, CLOSE limit switch, OPEN limit switch, pre-limit switch and,
where applicable, floor position and, where applicable, partial opening position are
programmed.
6: The smoke/heat ventilation position (RWA) is programmed.
7: The light barrier muting position is programmed.
0
215
0..1
Switching off the CLOSE limit position
In the CLOSE limit position, switch-off is possible via the safety edge or via the limit
switch
0: Switch-off via limit switch
1: Switch-off via safety edge
0
216
0..1
If using an absolute value encoder:
Floor adjustment
Activates the floor adjustment. The floor position determined during door setting is
saved. When closing, the moment the door touches the floor, the saved floor posi-
tion serves as a reference and enables the correction of the positions pre-limit
switch, door closed and the floor position itself. The correction is made in small
steps.
0: No floor adjustment
1: Floor adjustment active
0
220
[Inc]
0..4095
If using an absolute value encoder:
CLOSE limit switch position
The parameter value gives the CLOSE limit position in increments.
0
221
[Inc]
-100..100
If using an absolute value encoder:
Correction of the CLOSE limit position
Corrects the CLOSE limit position in increments
0
222
[Inc]
0..4095
If using an absolute value encoder:
Pre-limit switch position (VES)
The parameter value gives the pre-limit switch (VES) position in increments.
0
225
0..1
Relieving the safety edge
This parameter configures relieving the safety edge in the lower limit position (gen-
erally with DW). See also reversing time for relieving the safety edge. The relieving
position corresponds to the message "Door closed".
0: No relieving
1: Relieving
0
