Select with button (C) Select with rotary encoder (B) Store button (F)
ALTM SELECT GARMIN / TRIMBLE
NORTHSTAR
UPS AT (BECKER BE6400)
LORAN
MAGELLAN
SHADIN
ARNAV
GILHAM / PARALLEL default
store
store
store
store
store
store
store
store
DIMMING INPUT None
(set illumination intensity ma
-
nually in the configuration
menu)
+5V DC
+14V DC
+28V DC
default store
store
store
store
SQUITTER
Short ACQ SQU
*
default on off/on
REPLY RATE LIMIT RPL RATE LMT
500-1200 replies/sec.
in Mode A/C
(setting in steps of 50)
store
SPECIALS
DATA LINK
**
DEFAULT CONFIG ***
ALT HIGH RESOL
store
execute
store
Error Latch LOW VOLT
HIGH TEMP
ANTENNA
RF POWER
DME ERR
SQRT ERR
CORE EE
RECEIVER
FIX DATA
ALTIMETER
DATA LINK / GPS****
Clear latch
view only
view only
view only
view only
view only
view only
view only
view only
view only
view only
view only
execute
* Transponders equipped for extended squitter operation should have a me
-
ans to disable acquisition squitters to facilitate the suppression of acquisition
squitters when all TCAS units have been converted to receive extended
squitter.
** Shall be disabled if ADLP or similar device is not connected. The same is
also recommended if GPS receiver is used.
INSTALLATION AND OPERATION BXP6401-X-(XX)
Page 2-8
34-50-08 September 2011
