L. Configuration mode
The configuration mode is available from SBY mode only. To get into configu
-
ration mode press button SEL (G), turn rotary encoder (B) until “CFG” appe
-
ars in the bottom row of the display. Available options are defined in the fol
-
lowing table.
Select with push-
button (C)
Select with rotary
switch (B)
Store button (F)
BRIGHTNESS
(only if dimming input
is set to “none” in
installation menu)
0 %
…
50%
…
100 %
default
store
store
store
store
store
ILLUM CURVE
(only if external
illumination control is
set in the instal-
lation menu)
Characteristics store to change
VIEW CONFIG AI IN SBY
AI IN ON
FL IN ALT
default
default
default
ON
OFF
ON
OFF
ON
OFF
DEVICE INFO CU VER
CORE VER
FPGA VER
DEV TYPE
SERIAL NB
view only
view only
view only
view only
not supported
NOTE: The field “DEV TYPE” and “SERIAL NB” is not available.
INSTALLATION AND OPERATION BXP6401-X-(XX)
Page 3-10
34-50-08 September 2011
