Changing the flight number:
(1) Press SEL button (G).
(2) Rotate (B) until FN is displayed.
(3) Push (C) twice to enter the FN editing mode.
(4) Change the FN as described above.
G.2 VFR code presetting
Press the SEL button (G) to get into configuration mode (selection is indica-
ted in the left bottom corner of the display under the operating mode indica-
tion).
(1) Rotate (B) to the indication VFR=XXXX.
(2) First push to button (C) Þ left digit of the code is inverted.
(3) Now the digit can be changed with (B).
(4) Second push to button (C) Þ next left digit of the code is inverted.
(5) The next digit can be changed with (B)
(6) and the same for next digits.
(7) Fifth push to button (C) Þ again first digit is inverted.
(8) Changes can be stored with STO button (F) at any time, inversion stops
in this case.
(9) A VFR code that was preset in this way can be activated as described
in chapter I.
(10) A timeout for inversion (10 sec) is introduced if no action happens.
Nothing stored, as long as (F) is not pressed.
NOTE:
It is possible to leave the setting procedure with SEL button (G) at any time
and normal mode is available then. Indication SEL on the display changes
back to mode indication. If STO button (F) was not used, no change has been
stored.
INSTALLATION AND OPERATION BXP6401-X-(XX)
Page 3-7
34-50-08 September 2011
