Operating Instructions
14
Displays and pushbuttons
Functions
MAN/AUTO Sliding Switch
When the sliding switch is set to , manual control commands (e.g.: UP, STOP,
DOWN pushbutton commands) are executed and an alarm signal (e.g.: wind alarm if
wind sensor is integrated) given.
When the sliding switch is set to , automatic control commands are executed
(e.g. sun protection function, ...).
Transmission control light
A radio signal is indicated by the transmission control light being lit.
If the battery starts running out, the transmission control light flashes during trans-
mission.
The transmitter power and/or radio range is reduced when the battery is running
low. If the transmission control light is no longer lit when the pushbutton is pressed,
the batteries must be changed.
Sliding Switch
RETRACT button
STOP pushbutton
EXTEND button
Battery compartment
Setting aid
Wind threshold control switch
Sun threshold control switch
Programming pushbutton
Transmission control light
