Operating Instructions
17
• Before installing in the position re-
quired, check that the transmitter and
receiver are functioning properly.
• Fix the mount to the wall with the
two screws provided.
Installing the wall mount
38,5
95
43,6
2) Learning additional transmitters
a) Press the learn button of the master transmitter until acknowledgement is given
by the receiver.
b) Now press the learn button of the new transmitter until acknowledgement is
given by the receiver
c) Then press the learn button of the new transmitter to be learnt once again.
The receiver will indicate when the learn process has been successfully completed.
The maximum radio range is up to 25 m indoors and up to 350 m in the open.
