Beckhoff C6930 - Access to Components and Drives

Product Description
Access to the battery and drives
Access to the hard disk, the
CF-Card/ CFast-Card and
the battery
Opening the front flap (1) allows access to the battery (2), the CF-Card/
CFast-Card (3) and the hard disk (4). Optionally the Industrial PC can be
fitted with a second hard disk (5).
When provided with a CF-Card the ejection of the card occurs by pressing
the eject button below the card slot.
2
1
3
4
5
Danger of Explosion!
WARNING
Replace battery only with the identical type or an alternative type recommended by the
manufacturer. Notice correct polarity!
Polarity of the battery:
-
+
Handling of Lithium Batteries
WARNING
Lithium Batteries should not be recharged, exposed to fire, opened and they should be
protected against sunlight and moisture.
8 C6930
