Product overview
C9900-G05x 11Version: 1.0
Order option Description
C9900-G055 Compact push-button extension for CP3721-1600 or CP3921 with horizontal 21.5-inch
display
Push-button extension at the bottom, connection via 19-pin round connector
(customer)
4 push-button keys with signal lamp, type RAFI RAFIX 22FS+, round, 30 mm
1 emergency stop button, type RAFI RAFIX 22FS+
Labels for the push-button caps for individual labeling of each push-button can be
ordered as accessories
The emergency stop button and the red push-button key with signal lamp are each
wired potential-free to the 19-pin round connector with two break contacts. The green
push-button key with signal lamp is wired to the 19-pin round connector with two make
contacts, while the blue and white push-button keys with signal lamp are each wired to
it with one make contact.
All indicator lamps are also wired to the 19-pin round connector.
C9900-G057 Compact push-button extension for CP3724-1600 or CP3924 with horizontal 24-inch
display
Push-button extension at the bottom, connection via 19-pin round connector
(customer)
4 push-button keys with signal lamp, type RAFI RAFIX 22FS+, round, 30 mm
1 emergency stop button, type RAFI RAFIX 22FS+
Labels for the push-button caps for individual labeling of each push-button can be
ordered as accessories
The emergency stop button and the red push-button key with signal lamp are each
wired potential-free to the 19-pin round connector with two break contacts. The green
push-button key with signal lamp is wired to the 19-pin round connector with two make
contacts, while the blue and white push-button keys with signal lamp are each wired to
it with one make contact.
All indicator lamps are also wired to the 19-pin round connector.
The installation of mechanical extensions under the compact push-button extension is not possible.
