Product overview
C9900-G05x 9Version: 1.0
3.1 C9900-G05x ordering options
Table1: USB/ directly wired versions
Order option Description
C9900-G050 Compact push-button extension for CP3716-1600 or CP3916 with horizontal 15.6-inch
display
Push-button extension at the bottom, connection via USB (factory) and 19-pin round
connector (customer)
3 push-button keys with signal lamp, type RAFI RAFIX 22FS+, round, 30 mm
1 emergency stop button, type RAFI RAFIX 22FS+
Labels for the push-button caps for individual labeling of each push-button can be
ordered as accessories
The emergency stop button is wired potential-free to the 19-pin round connector with
two break contacts. The red push-button key with signal lamp is wired potential-free to
the 19-pin round connector with one break contact, while the green and blue push-
button keys with signal lamp are each wired to it with one make contact.
In addition, all push-buttons with a make contact are queried via USB.
All LEDs of the push-button keys with signal lamp are controlled only via USB.
C9900-G052 Compact push-button extension for CP3718-1600 or CP3918 with horizontal 18.5-inch
display
Push-button extension at the bottom, connection via USB (factory) and 19-pin round
connector (customer)
3 push-button keys with signal lamp, type RAFI RAFIX 22FS+, round, 30 mm
1 emergency stop button, type RAFI RAFIX 22FS+
Labels for the push-button caps for individual labeling of each push-button can be
ordered as accessories
The emergency stop button is wired potential-free to the 19-pin round connector with
two break contacts. The red push-button key with signal lamp is wired potential-free to
the 19-pin round connector with one break contact, while the green and blue push-
button keys with signal lamp are each wired to it with one make contact.
In addition, all push-buttons with a make contact are queried via USB.
All LEDs of the push-button keys with signal lamp are controlled only via USB
C9900-G054 Compact push-button extension for CP3721-1600 or CP3921 with horizontal 21.5-inch
display
Push-button extension at the bottom, connection via USB (factory) and 19-pin round
connector (customer)
4 push-button keys with signal lamp, type RAFI RAFIX 22FS+, round, 30 mm
1 emergency stop button, type RAFI RAFIX 22FS+
Labels for the push-button caps for individual labeling of each push-button can be
ordered as accessories
The emergency stop button is wired potential-free to the 19-pin round connector with
two break contacts. The red push-button key with signal lamp is wired potential-free to
the 19-pin round connector with one break contact, while the green, blue and white
push-button keys with signal lamp are each wired to it with one make contact.
In addition, all push-buttons with a make contact are queried via USB.
All LEDs of the push-button keys with signal lamp are controlled only via USB.
