Technical data
C9900-G05x32 Version: 1.0
8 Technical data
Table18: Characteristics of the respective push-button extensions
Properties Description
Order designation C9900-G050, C9900-G051, C9900-G052, C9900-G053, C9900-G054,
C9900-G055, C9900-G056, C9900-G057
Operating temperature CP37xx-1600-0020 0...45°C
CP39xx-0000 0...55°C
CP39xx-0010 0...50°C
Shock resistance
(sinusoidal vibration)
EN 60068-2-6: 10 to 58 Hz: 0.035 mm
58 to 500 Hz: 0.5 G (~ 5 m/s²)
Shock resistance (shock) EN 60068-2-27: 5 G (~50 m/s²), duration: 30ms
Protection class IP65
Supply voltage 24V
DC
(20.4– 28.8V
DC
)
Min. operating voltage AC/DC 5 V
Max. operating voltage AC/DC 35 V
Min. operating current AC/DC 1 mA
Max. operating current AC/DC 100 mA
Switching capacity max. 250 mW
EMC interference immunity conforms to EN 61000-6-2
EMC interference emission conforms to EN 61000-6-4
Permissible relative air humidity Maximum 95%, no condensation
Certifications CE, UL
Max. cable length 30 m
Table19: Characteristic values emergency stop and push-buttons
Properties Description
Min. operating current AC/DC 1 mA
Max. operating current AC/DC 100 mA
Switching capacity max. 250 mW
Protection class IP65
Emergency stop type 1.30.273.512/0030 Rafi 22FS+
The emergency stop is reset by rotating.
Service life 50,000 cycles
B10 value 65,000 cycles
Switching elements (emergency
stop)
1.20.126.414/0000 Rafi FS 1 x make contact / 2 x break contact
Service life 1 million cycles at 10 mA / 24 V DC
B10 value 65,000 cycles
Illuminated push-button type 9.30.270.027/1500 Rafi 22FS+ Green
9.30.270.027/1300 Rafi 22FS+ Red
9.30.270.027/1600 Rafi 22FS+ Blue
9.30.270.027/1000 Rafi 22FS+ Clear
Service life 1,000,000 cycles
B10 value 1,300,000 cycles
Switching element (push-buttons) 1.20.126.003/9000 1 x make contact / 1 x break contact
1.20.126.005/9000 2x make contact
1.20.126.004/9000 2x break contact
Service life 1,000,000 cycles
B10 value 1,300,000 cycles
