Beckhoff CP62 Series User Manual

Installation Instructions
Mounting of the Panel PC
Please refer to the chapter Assembly dimensions for Panel PC cutout
dimensions. Similar pictures.
Mounting of the Panel PC
Clamping levers
Release clamping levers,
Insert the PC into the cutout.
Release the clamping levers with a
No. 2.5 Allen key.
Folding them out
Turn the clamping levers to the side
through 90°
and retighten them.
and retighten the screws.
CP62x9-xxxx-0020 11
