Appendix
Appendix
Assembly dimensions
Built-in Panel PC CP6209-000x-0020
Notice mounting orientation
Attention
The assembly of the unit must take place with the orientation diagrammed
here.
All dimensions are in mm.
installation depth
front view
rear view with install measure
bottom view
rear view
side view
CP62x9-xxxx-0020 25
