Operating Instructions
Replacement for the
15 inch display
First release the two screws
(1) and (2) with a small Philips
screwdriver, then carefully pull
out the fluorescent lamps in
direction of the arrows.
After the exchange of the
fluorescent lamps the
installation takes place in
reverse order.
1
2
Lamp sets
Order number
Background illumination unit for
C9900 - L364
12 inch TFT display LTD121C30S
C9900 - L366
15 inch TFT display LQ150X1LW71N
Emergency procedures
In case of fire, the Industrial PC should be extinguished with powder or
nitrogen.
Shutting down
Disposal
Dismantle the Industrial PC
Observe national
electronics scrap
regulations
The device must be fully dismantled in order to dispose of it. The housing
can be sent for metal recycling.
Electronic parts such as lamps and circuit boards must be disposed of in
accordance with national electronics scrap regulations.
20 CP62xx
