Product Description
8 CP6700-0001-00x0/ CP6706-0001-00x0
2.2 Appropriate Use
The CP670x built-in Panel PC is designed for installation in the front of a control cabinet or control
housing. A steel plate housing with aluminum front contains a TFT display with touch screen.
Danger
Risk of explosion!
The Panel PC must not be used where there is a risk of explosion.
2.3 Access to the connectors
The connectors of the Panel PC are located at the bottom of the housing.
Picture: Bottom view
