Product Description
CP6700-0001-00x0/ CP6706-0001-00x0 11
2.5 Access to the battery and the CFast card slot
The battery and the CFast card slot are located behind a cover at the bottom side of the Panel PC:
For replacing the battery and installation of the CFast card first unloose the two Torx screws (1) with a
srew driver T10. The cover plate (2) can now be removed.
Replace battery only with the identical type or an alternative type recommended by the
manufacturer. Notice correct polarity!
Handling of Lithium Batteries
Lithium Batteries should not be recharged, exposed to fire, opened and they should be
protected against sunlight and moisture.
