Product Description
2.5 Connection Kits
One 5-pole power supply connector is provided with the Control Panel.
Optionally prefabricated connection kits for the DVI-E/ USB-E connection are available.
2.5.1 Connection Kits DVI-E/ USB-E connection for CP69xx, optional
The following connection kits are available:
Connecting kit DVI-E/ USB-E Connection
C9900-K513
Connecting kit 3 m for CP69xx, containing:
3 m DVI cable, 3 m USB cable
C9900-K515
Connecting kit 5 m for CP69xx, containing:
5 m DVI cable, 5 m USB cable
C9900-K421
Connecting kit 10 m for CP69xx, containing:
10 m DVI cable, 10 m CAT 5 cable for USB-E, USB to USB-E converter CU8800 for
mounting rail installation close to the PC and 1 m USB cable to connect the USB to
USB-E converter to the PC
C9900-K423
Connecting kit 20 m for CP69xx, containing:
20 m DVI cable, 20 m CAT 5 cable for USB-E, USB to USB-E converter CU8800 for
mounting rail installation close to the PC and 1 m USB cable to connect the USB to
USB-E converter to the PC
C9900-K425
Connecting kit 30 m for CP69xx, containing:
30 m DVI cable, 30 m CAT 5 cable for USB-E, USB to USB-E converter CU8800 for
mounting rail installation close to the PC and 1 m USB cable to connect the USB to
USB-E converter to the PC
C9900-K427
Connecting kit 40 m for CP69xx, containing:
40 m DVI cable, 40 m CAT 5 cable for USB-E, USB to USB-E converter CU8800 for
mounting rail installation close to the PC and 1 m USB cable to connect the USB to
USB-E converter to the PC
C9900-K429
Connecting kit 50 m for CP69xx, containing:
50 m DVI cable, 50 m CAT 5 cable for USB-E, USB to USB-E converter CU8800 for
mounting rail installation close to the PC and 1 m USB cable to connect the USB to
USB-E converter to the PC
CP69xx 11
