Operating Instructions
UPS Software Components (optional)
Installing the UPS driver
software
For operating the power supply unit as a UPS, the UPS driver software and
the associated UPS driver must be installed on the Industrial PC.
On delivery of the Beckhoff Industrial PC with operating system the
software is already installed. Should the software not be installed on your
PC, the drivers can be installed from the driver CD provided.
Installation on the PC
Installation
To install the UPS driver software, execute file
Beckhoff_UPS_vx.xx.xx.exe from the subdirectory of UPS\… from the
CD provided on the Industrial PC (Driver-archive for the Industrie-PC,
C9900-S700-xxxx). There you also find the help-file (TcUpsShellExt.chm)
before the installation of the software.
Start the driver-software (Start > Run > Program). The program is self-
extracting and will guide the user through the installation routine.
Help files
Beckhoff information
system
The driver software comes with a detailed help function.
The help files can be called up either directly from the configuration register
by clicking the Help button, or under via Start > Programs > Beckhoff >
UPS software components.
i
Note
Please note that the background illumination of the Panel is not switched
on in the case of activation power supply of the Industrial PC over the UPS.
In this case the Panel shows no picture.
16 CP71xx
